280Ah Welding Battery Module
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
1.Balanced heat transfer performance, excellent cooling conditions and homogeneity of temperature.
2.Design for application on vehicles, reliable structural strength and stability.
3. Laser welding manufacturing techniques to guarantee stable electronic connection.
Form：
|
Model |
ZNCM00130280C03A01 |
ZNCM00160280C03A01 |
ZNCM00190280C03A01 |
|
Battery Type |
LFP |
LFP |
LFP |
|
Configuration |
1P4S |
1P5S |
1P6S |
|
Rated Voltage |
12.8V |
16V |
19.2V |
|
Rated Capacity |
280Ah |
280Ah |
280Ah |
|
Rated Energy |
3.584kWh |
4.48kWh |
5.376kWh |
|
Protection Rating |
IP20 |
IP20 |
IP20 |
|
Weight |
25.4kg |
30.9kg |
36.24kg |
|
Dimensions(W*D*H) |
177.5*337.5*221.2mm |
177.5*408.8*221.2mm |
177.5*480.5*221.2mm |
|
Cycle Life |
≥6000 cycles |
≥6000 cycles |
≥6000 cycles |
