400-1000kWh Electric Ship/Marine Battery System

400-1000kWh-Battery-System-for-Ship-Datasheet.pdf

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Description

Form：

Battery Power (kWh)	Capacity of Battery Cell （Ah）	Single Voltage （VDC）			Battery Group	Parallel	Series	System Voltage （VDC)			System Capacity(Ah)	Capacity of box approved by CCS				A box Spec	A box Weight	B box Spec	B box Weight	C box Spec	C box Weight	D box Spec	D box Weight	Battery box Total weight	Energy Density	System level allows charging current		Ship type/ Driving System
Battery Power (kWh)	Capacity of Battery Cell （Ah）	Lower limit	Rated	Upper limit	Battery Group	Parallel	Series	Lower limit	Rated	Upper limit	System Capacity(Ah)	A	B	C	D	A box Spec	A box Weight	B box Spec	B box Weight	C box Spec	C box Weight	D box Spec	D box Weight	Battery box Total weight	Energy Density	System level allows charging current		Ship type/ Driving System
483.84	105	2.9	3.2	3.50	2	4	180	522.0	576.0	630.0	420	40				2P18S	95	3P12S	95	1P12S	80	1P30S	200	3800	127	2	420	Cruise ship/sightseeing boat/hybrid ship ; Dual main propulsion/auxiliary propulsion, retrofit ship, new shipbuilding
725.76	105	2.9	3.2	3.50	2	6	180	522.0	576.0	630.0	630		60			2P18S	95	3P12S	95	1P12S	80	1P30S	200	5700	127	2	630
645.12	280	2.9	3.2	3.50	2	2	180	522.0	576.0	630.0	560			60		2P18S	95	3P12S	95	1P12S	80	1P30S	200	4800	134	2	560
645.12	280	2.9	3.2	3.50	2	2	180	522.0	576.0	630.0	560				24	2P18S	95	3P12S	95	1P12S	80	1P30S	200	4800	134	2	560
532.22	105	2.9	3.2	3.50	2	4	198	574.2	633.6	693.0	420	44				2P18S	95	3P12S	95	1P12S	80	1P30S	200	4180	127	2	420
774.14	105	2.9	3.2	3.50	2	6	192	556.8	614.4	672.0	630		64			2P18S	95	3P12S	95	1P12S	80	1P30S	200	6080	127	2	630
688.13	280	2.9	3.2	3.50	2	2	192	556.8	614.4	672.0	560			4	24	2P18S	95	3P12S	95	1P12S	80	1P30S	200	5120	134	2	560
731.14	280	2.9	3.2	3.50	2	2	204	591.6	652.8	714.0	560			8	24	2P18S	95	3P12S	95	1P12S	80	1P30S	200	5440	134	2	560
798.34	105	2.9	3.2	3.50	2	6	198	574.2	633.6	693.0	630	66				2P18S	95	3P12S	95	1P12S	80	1P30S	200	6270	127	2	630
1161.22	105	2.9	3.2	3.50	2	9	192	556.8	614.4	672.0	945		96			2P18S	95	3P12S	95	1P12S	80	1P30S	200	9120	127	2	945
1032.19	280	2.9	3.2	3.50	2	3	192	556.8	614.4	672.0	840			6	36	2P18S	95	3P12S	95	1P12S	80	1P30S	200	7680	134	2	840
1096.70	280	2.9	3.2	3.50	2	3	204	591.6	652.8	714.0	840			12	36	2P18S	95	3P12S	95	1P12S	80	1P30S	200	8160	134	2	840
