Rack Mounted Industrial & Commercial Energy Storage System
1. Modular structure design is able to compose varieties of electric voltage platform flexibly, all kinds of capacity level systems, and easy to maintain or repair.
2. The design of battery management system provides the highest reliability.
3. Making use of lithium iron phosphate batteries with high safety character, long cycling life, and more than ten years service life.
4. Small size, light weight, convenient to transport and deliver, and can be quickly equipped to all kinds of occasions.
Form：
|
Battery Type |
LiFePO4 |
|
Battery Cabinet Configuration |
(5~15) Battery Boxes And 1 Control Box |
|
Nominal Voltage |
51.2V*（5~15） |
|
Nominal Capacity |
100Ah/200Ah |
|
Nominal Total Energy |
5.12*（5~15）kWh |
|
Electrical Parameters |
|
|
Voltage Range |
44.8V*（5~15）～57.6V*（5~15） |
|
Standard Charging Current |
50A |
|
Max.Charging Current |
100A |
|
Standard Discharge Current |
50A |
|
Max.Discharging Current |
100A |
|
Mechanical Parameters |
|
|
Net Weight |
350~920kg |
|
Dimension (W*D*H) |
1110*420*[(3~8)*230+190]mm |
|
Ingress Protection |
IP20 |
|
Cooling |
Natural Cooling |
|
Operation Condition |
|
|
Environment Temperature |
Charge：0℃～55℃/ Discharge：-20℃～55℃/ Storage：-10℃～30℃ |
|
Operation Humidity |
5~95%，RH |
|
Altitude |
< 2000m |
|
Mounting Type |
Stationary |
|
Design Life |
> 10 years |
